Portable pH/ORP meter LX102PPO is a microprocessor-based meter that measures hydrogen-ion activity in water-based solutions. Automatic or manual temperature compensation provides high-accuracy results. Provision for 1-3 point automated push button calibration. Meter factory reset function to reset factory default settings and data logs for convenient operation.
pH range | 0 ~ 14 pH |
pH resolution | 0.01 pH |
Electrode | Plastic ORP (LX6010) |
Calibration point | 1-3 points |
Electrode liquid junction | Fiber |
pH accuracy | ± 0.01 pH |
ORP range/RmV | ± 1999 mV/RmV |
ORP resolution | 1 mV |
ORP accuracy | ± 2 mV |
Temperature range | 0 ~ 99.9 °C |
Temperature resolution | 0.1 °C |
Temperature accuracy | ± 0.5 °C |
Temperature compensation | 0-99.9°C manual/auto |
Ambient temperature | 5 °C ~ 45 °C |
Input connector type | BNC |
Input connector diameter | 3.5 mm |
Output | USB |
Power | 100 V ~ 240 V DC 9 V 500 mA |
pH buffer Set | USA, NIST, DIN, Manual |
Memory | 500 sets |
Electrode slope display for easy judgment of electrode performance
Automatic calibration of RmV function
Auto-sleep function
Segmented display for pH, mV and temperature
Electrode slope display for user interpretation
Self-diagnostic trouble shoot
Low battery indicator
USB communication interface via data transfer (output)
Stability and average function for optimized results
Electrode | Plastic pH (LX6010) |
pH range | 0 ~ 14 pH |
Temperature range | 5 °C ~ 60 °C |
Dimensions | 12 mm x 160 mm |
Liquid junction | Fiber |
Reference junction | Single / Sealed |
Internal reference type | Ag/AgCl |
