Vertical Autoclave LX101VA

Vertical Autoclave LX101VA

Vertical Autoclave LX101VA is a sterlizing mechanism made by SUS304 fully stainless steel with top loading sterlizer along with safety protection features like heat protection, Anti dry heating, safety interlock door, Over-Temprature and over pressure protection, Automatic release safety valve, Electric safety protection device and emergency exhaust switch for safe and effective sterlizing process. It’s equipped with dual scale numarical pressure guage for pressure and temprature indication, easy control panel and silicon ruber seal for protection against leakage. This mechanism is very effectivly useful in hospitals, clinical laoratories, research centers, science colleges for sterlization of glass wares, biological materials, cultural media, surgical instrument, rubber material etc.

Generate Catalog
Volume of Chamber50 Liters
Sterilizing Chamber Volume(mm)Ø320 X H610
Working Pressure0.22 Mpa
Max Working Pressure0.23 Mpa
Working Temperature134 °C
Adjustment of Temperature0 - 134 °C
Timer0-80 min
Heat Average≤ ± 1℃
PowerAC 220 V / 50 Hz
Product Dimension (mm)500 X 510 X 1010
Package Dimension (mm)570 X 550 X 1040
Gross Weight54 Kg

Dual scale numerical pressure guage for pressure and temprature indication

Equipped with knobs to fix sterlization time and temprature

Electric heating or direct heating by immersing copper tubes of heating elements

Silicon ruber seal for protection against leakage

Equipped with automatic shutdown facility with beep voice indication when sterlization complets

Automatic power cut off for prevent from overheating

Alarms for indentify overheating

Faciliate with safety features

Reliable and user friendly

Vertcial Autoclave is used in Biotechnology, microiology, medical and healthacare industry, scientific research center, school, college, university for seterlizing process.
