Hematology analyzer LX300HMA 3-part differentiation fully automatic unit that can carry out 60 tests per hour. It features a built-in external thermal printer and it automatically calculates CV%, and SD also saves data. Stores more than 200,000 results including histograms. It is used widely in patients and research. All the functions are highly efficient, easy and fast to operate.
| Throughput | 60 tests/hour |
| Measuring principle | Coulter principle Colorimetry hemoglobin determination |
| Parameter | WBC, LYM#, MID#, GR#, LYM%, MID%, GR%, RBC, HGB HCT, MCV, MCH, MCHC, RDW-SD RDW-CV, PLT, MPV, PDW, PCT, P-LCR, P-LCC |
| Histograms | 3 Histograms (including WBC, RBC, PLT) |
| Sampler volume | Pre-dilute: 20μl Whole blood, peripheral blood: 10μl |
| Display | 10.4 inch color touch screen display |
| Intelligent reagent management function | Reagent information and residual display |
| Data search mode | By Sample ID, Patient ID, Date, Multi-keywords. loading/extracting data and offline reading |
| Operation mode | Touch screen, Keyboard/mouse |
| Quality control | L-J, X-R, X-B, etc |
| Printer | Built-in thermal printer (external printer) |
| Operating environment | Temperature: 10-35°C Humidity: ≤90% |
| Data communication | LIS, HL7 |
| Ports and Wireless connection | LAN x 1, RS232 x 1, HDMI x 1, USB Port x 4 Wi-Fi, Bluetooth |
| Power supply | 110-240V 50/60 Hz |
| Dimension dimension (W x D x H) | 440 x 350 x 440 mm |
| Net weight | 17 kg |
| Package dimension (W x D x H) | 670 x 560 x 600 mm |
| Gross weight | 25 kg |
It has an electrical impedance method principle, cyanide-free hemolytic agent testing HGB
Equipped with touch screen display, External printer with RS232
Easy to operate, Friendly and Intellective Software
Designed with 3-part differentiation of WBC and 21 parameters + 3 histograms
The handled barcode scanner is optional
Intelligent reagent management function
Storage capacity is more than 200,000 data
| Parameter | Linearity range | Precision (CV%) |
| WBC(109/L) | 0.0-100.0 | 2.0 (4.0-10.0) |
| RBC(1012/L) | 0.00-9.99 | 1.5 (3.50-5.50) |
| HGB(g/L) | 0-300 | 1.0 (110-160) |
| PLT(109/L) | 0-1000 | 5.0 (100-300) |
